The Replicator™ .

a multi-frequency, multi-system GNSS simulator for advanced R&D, equipment testing and education,

it can also function as a recording, playback and signal analysis instrument.

Some of the advantages

1. User defined models with ANSI C API.

2. Real-time simulation

3. Record and playback

4. GNSS signal analysis

5. Upgradable to more features , signals and frequencies for the difference in price.

Components:

1) Simceiver™ hardware device,

2) ReGen™ control software for real-time simulation,

3) Streamer software for recording and playback,

4) ARAMIS™ software receiver for signal analysis.

The Replicator™ is a result of our 7-year work for and collaboration with the Japan Aerospace Exploration Agency (JAXA).

iP-SOlutions, Japan GNSS, GPS, GLONASS, BeiDou, Galileo multi system, dual frequency RF simulator,recorder,playback

The ReGen™ is a control center software for multi-frequency, multi-system GNSS simulator. It is intended for advanced R&D, equipment testing and education.

It also allows off-line simulation of digitized GNSS signal, similar to those recorded from life satellites. The signal can be played back as RF at later time or analysed by MATLAB receiver.

Sreamer software can record and playback dual frequency GPS, GLONASS and BeiDou signals.

GPS GLONASS Galileo BeiDou QZSS recorder to record and playback GNSS RF signals and USB front end for SDR

- Real-time simulation of one of the follows :

dual frequency GPS, GLONASS, BeiDou or GPS+GLONASS, GPS+BeiDou, GPS+Galileo signals (see Table below for available signals).

- Comprehensive simulation models including atmosphere, multipath etc.(see ReGen datasheet)

- Record and playback dual frequency GPS/Galileo, GLONASS and BeiDou signals.

- Two or more units can be used to simulate, record and playback more signals at the same time.

- Signal analysis based on JAXA COSMODE ionospheric scintillation monitor.

- Simulated and recorded signals can be stored in digitized format , analysed by a MATLAB software receiver and played back as RF at any time.

Versions (see details )

Standard

Professional

Single channel simulator with custom Doppler profile simulation.

Development with API

ANSI C API allows to modify existing or implement custom models for signal simulation .

iP-SOlutions, Japan GNSS, Reference Station Receiver Data Generator allows to generate raw data and then RF signals for up to four locations with spatially correlated models.

Reference Station Receiver Data Generator allows to generate raw data and then RF signals for up to four locations with spatially correlated models. The signals can be played back as RF signals. This option is useful for RTK, VRS or LAAS simulation.

Simceiver™ AG hardware option supports E5, L5 signals with 24-MHz bandwidth.

Eagle front end allows to record two L1 signals GPS/Galileo + GLONASS /BeiDou, which can be played back with the Replicator™.

Power control

Real-time between channels 20 dB

Resolution 1 dB

Connectors

RF IN , RF OUT SMA female,

USB-2 Bi-directional to Host PC

Trigger, 1 PPS IN, OUT Yes

External clock IN, OUT SMA female , 10 MHz.

Power 5 VDC , less then 3 W

Accuracy

Code phase less than±10 cm RMS

Carrier phase less than±5 cm RMS

Time base OCXO option

Aging ±2 ppb/day

Stability ±10 ppb over -20º C to +70º C

Environmental

Operating temperature +10~40℃

Operating humidity 40~90%RH(non-condensing)

Dimensions 200×120×70

Weight w/o control PC less than1 kg

Control software

Windows OS

Ionospheric models

Klobuchar

NeQuick

ionospheric gradient error editor

scintillation simulation

TEC depletion simulation

fault scenarios (FAA CAT-1 LAAS)

Tropospheric models

Saastamoinen

Hopfield

Black

Miscellenious models

step, ramp, acceleration code and carrier errors

orbital parameters (true and broadcast)

navigation message parameters and bits

antenna pattern editor

multipath simulation

Dynamic user simulation

GNSS network simulation

Read our articles on simulation:

GNSS Simulation: A User’s Guide to The Galaxy

GPS simulation

Testing Multi-GNSS Equipment: Systems, Simulators, and the Production Pyramid

GNSS Simulators: Everything You Always Wanted to Know But Were Afraid to Ask

GPS simulation

Replicator-X

Up to 20 signals at the same time.

Download datasheet

iP-SOlutions, GNSS RF simulator card

Six Pegasus RF cards

iP-SOlutions, GNSS RF simulator card

Available signal licenses for Replicator-X (subsets are available for Replicator and Simceiver):

Pegasus rf card signals (optional sets are indicated by || )
Card P1 GPS L1CA, GPS L1C, QZSS L1CA, QZSS L1C, BDU B1C, GAL E1, SBAS L1
Card P2  BDU B2I, GPS L2C, QZSS L2C, GAL E5B, GLO L3OC
Card P3 GPS L5, BDU B2A, GAL E5A, NAVIC L5, SBAS L5
Card P4 BDU B3I || GLO L2OF, GLO L2OS || QZSS LEX
Card P5  NAVIC S || GLO L1OF, GLO L1OS
Card P6 BDU B1I

CRPA Replicator variant.

Up to 6 vehicles/antennas with up to 7 GNSS signals at the same time.

Six Pegasus RF cards

iP-SOlutions, GNSS RF simulator card

Ninja CRPA simulator with PORTOS CRPA front end

iP-SOlutions, Japan GNSS, GPS, GLONASS, BeiDou, Galileo multi system, dual frequency RF simulator,recorder,playback Replicator  test with U-Blox GPS receiver

Ionospheric models include NAVIC grid model now

iP-SOlutions, NAVIC simulaton

Replicator test with U-Blox GPS receiver:

Replicator screenshot after 4 hour operation:

iP-SOlutions, Japan GNSS, GPS, GLONASS, BeiDou, Galileo multi system, dual frequency RF simulator,recorder,playback Replicator  test with U-Blox GPS receiver

uBlox screenshot after working with Replicator for 4 hours. Less than 50 cm CEP

iP-SOlutions, Japan GNSS, GPS, GLONASS, BeiDou, Galileo multi system, dual frequency RF simulator,recorder,playback Replicator  test with U-Blox GPS receiver

Verify signal with our ARAMIS™ receiver
